HY-R386A High Configuration 8-Ports UHF RFID Reader,are RFIDHY new designed masterpiece with great innovations – a real IOT smart UHF RFID reader, supporting edge computing，which help turn on the value of data into a networking times. They run with Impinj INDY R2000/E710 high...
$680 – $785/pc
MOQ: 1 pcs · Volume discounts available on request
Select all specifications before choosing quantity or starting checkout. No option will change another selection.
$680.00 – $785.00
Secure checkout via PayPal
| Connector | POE, TCP/IP |
|---|---|
| Size(mm) | 241mm×132mm×36mm |
| Processor | MT6765, Octa-Core 2.3Ghz |
| Memory | Flash 16GB; DRAM2GB |
| Operating System | Android 9.0 |
| Firmware Upgrade | Demo software / Web |
| API Support | Android – Java |
| Dimensions | 241mm×132mm×36mm |
| Weight | 1.2Kg |
| Housing Material | Die-cast aluminum |
| Visual Status Indicators | Power/Status, Ant 1-4/8 |
| Air Protocols | ISO/IEC18000-6B, 6C / EPC C1Gen2 C2GEN2 optional |
| Frequency | USA: 902 MHz-928MHz (FCC part 15) CN: 920-925MHz (CMIIT) Russian / Brazil / Korea / Malaysia / Thailand /other customizable |
| Output Power | 0dBm-35dBm (±1dBm) adjustable |
| Channel bandwidth | ＜200KHz |
| Anti-collision | Support multi-tag / intensive inventory |
| Work Mode | Fixed/hop frequency optional |
| Communications | RJ45, RS-485, OTG, Wiegand WiFi : 802.11 a/b/g/n/ac 4G：LTE-FDD（CAT-7）/LTE-TDD（CAT-7）/ WCDMA/TD-SCDMA/EVDO/CDMA/GSM Bluetooth：BT v2.1+EDR，3.0+HS,v4.1+HS |
| General Purpose I/O | 4 inputs(DC 0~24V), 4 outputs(DC_MAX:30V,2A; AC_MAX:125V,0.3A), optically isolated (Terminal Block) |
| Power supply | DC 24V/2.5A (DC 9V ~ 30V,60W) or PoE (IEEE 802.3 af/at/bt), support max 33db output |
| Display interface | HDMI, support 720P(default)/1080P |
| Antenna Ports | 4 Reverse Polarity TNC ports; circular or linear polarization; near and far field compatible |
| Operating Temp | -20 – +70°C |
| Storage Temp | -40 – +85°C |
| Humidity | 5-90% non-condensing (+25°C) |
| Sealing | IP5X |
HY-R386A High Configuration 8-Ports UHF RFID Reader,are RFIDHY new designed masterpiece with great innovations – a real IOT smart UHF RFID reader, supporting edge computing，which help turn on the value of data into a networking times. They run with Impinj INDY R2000/E710 high performance RFID chipset, and operated on Android 9.0 operation system. 8-Port.
It supports off-line working for 40,000pcs of tags since with 2GB RAM and 16G ROM capacity. Kinds of communication interfaces, PoE optional.
Moreover, it could be connected with monitor via the HDMI interface.
WE SUPPORT RFID TAG OEM SERVICE
● Powered by Impinj R2000 chipset/E710 for maximum tag detection performance
● Android OS based open development environment
● Support MQTT provides real-time, reliable messaging services for connecting cloud servers
● Support HTTP POST communication to send the tag data to the web URL directly
● Support to send the tag data to the specified database directly
● Kinds of communication interfaces: RJ45, RS485, Wiegand, USB, Wi-Fi,Bluetooth, 4G
● Industrial, installation friendly I/O connector
● Support RSSI, speed filters, antenna detection, online update
● Real useful PoE (max 33dbi power output) supportable
